2. Characteristics
1) Use of the foot-operated hydraulic pump integrating oil pump, oil tank and mechanical transmission mechanism
2) Table can be operated by two cranks at head end position
3) Reasonable structure, modern design and complete accessories
4) Simple and flexible operation, safe and reliable positioning
5) Base cover, column and side rail are made of stainless steel.
6) Table with blocking system located in one side of the base.
|
Technical parameters
|
|
Length and width of tabletop
|
2100mm×480mm
|
|
Min. & Max. height of tabletop
|
700mm~1045mm
|
|
Degree of Trendelenburg/Reverse Trendelenburg of table
|
30°/30°
|
|
Degree of Lateral tilting of table
|
25°/25°
|
|
Range of back board adjustment
|
upward ≥80° downward ≥10°
|
|
Range of head board adjustment
|
upward ≥90° downward ≥90°
|
|
Range of leg board adjustment
|
downward ≥90°
|
|
Elevating height of kidney bridge
|
≥120mm
|
|
Mattress height
|
50mm
|
|
Standard Accessories
|
|
Knee crutch
|
1 pair
|
|
Body support
|
1 pair
|
|
Shoulder support
|
1 pair
|
|
Arm support
|
1 pair
|
|
Anesthesia screen frame
|
1 pc
|
